型 號:SHT255
電 機:72V3000W 電機;超大功率滿盤電機
控制器:72V 智能化控制系統
電 池:72V 40Ah 磷酸鐵鋰電池
顏 色:客戶可定制
蘇華特 SHT255 電動摩托車 技術參數(出口型)
Technical Parameters of Suhuate SHT255 Electric Motorcycle (Export Version)
產 品 Product | 名稱 Name | 電動摩托車 Electric Motorcycle |
品牌 Brand | 蘇華特 SUHUATE | |
型號 Type | SHT255 | |
電 器 系 統 Electrical system | 電控 Electric control | 72V 智能化控制系統;無級調速 ,制動斷電 ,欠壓保護 ,過 流保護等性能 ,穩定。72V 12 管 控制器 ,強勁快速。72V intelligent control system; It has stable performance features such as stepless speed regulation, power cut-off during braking,under-voltage protection, over-current protection, etc. A 72V 12-tube controller provides strong and rapid performance. |
鋰電池 Lithium battery | 72V 40Ah 磷酸鐵鋰電池 72V 40Ah lithium iron phosphate battery | |
電機 Motor | 72V3000W 電機;超大功率滿盤電機 ,動力持久強勁, 爬坡能力 ,載重能力強。72V3000Wmotor; It is a super high-power full-disc motor, offering lasting and powerful performance, with strong climbing ability and high load-bearing capacity. | |
充電器 Charger | 72V 充電平穩、耐高溫With 72V, the charging process is stable and it can withstand high temperatures. | |
充電時間 Charging time | 6-8小時 6-8hours | |
音響 Audio system | 電喇叭Electric horn | |
車 身 配 置 Body matching
| 顏色 Color | 客戶可定制 which can be customized by customers. |
座高Seat height | 760mm | |
手把高handlebar height | 980mm | |
車體Body | 鋼制車架+塑料外殼 Steel frame + plastic shell | |
儀表臺Dashboard | 多功能液晶數碼儀表盤 ,功能齊全Dashboard: Multi - function LCD digital instrument panel with complete functions. | |
后視鏡Rearview mirrors | 左右各一手動型外后視鏡Rearview mirrors: One manual external rearview mirror on each of the left and right sides. | |
燈光及信號Lights and signals | 前照燈 ,前后轉向燈 ,組合后尾燈 ,電喇叭;凌厲霸氣的水 晶的前大燈 ,按照仿生學原理設計 ,外形更美觀 ,照明更安全 Headlights, front and rear turn signals, combined rear taillights, and an electric horn. The sharp and imposing crystal headlights are designed in accordance with the principles of bionics, featuring a more aesthetically,pleasing appearance and ensuring safer illumination. | |
底 盤 Bottom plate | 動力傳動系統Power transmission system | 無級調速系統 Stepless speed control system |
驅動系統 Drive system | 后軸驅動 Rear axle drive | |
制動系統 Brake system | 前后雙碟剎,采用摩托車級別工藝,雙后減,性能優越Front and rear double disc brakes, using motorcycle-level craftsmanship, double rear shock absorbers, superior performance. | |
最低離地minimum ground clearance | 245mm | |
轉向角度steering angle | 35-37 | |
前伸角度reach angle | 28 | |
輪胎 Tyre | 前輪120/70/14 后輪 140/70/14 Front wheel: 120/70/14 Rear wheel: 140/70/14 | |
外形尺寸 長*寬*高 Size Length * Width * Height (mm) | 1980×745×1060 mm | |
整車裝備質量 Vehicle curb weight | 83kg | |
整車載荷 Vehicle load-carrying capacity | ≤300kg | |
軸距 Wheelbase | 1330 mm | |
額定乘員 Rated passenger capacity | 2 人(含駕駛員) 2 persons (including the driver). | |
初速 30km/h 制動距離 Braking distance at an initial speed of 30km/h | ≤6.5 m | |
最大行駛速度 Maximum travel speed | ≤80km/h | |
續駛里程 Range | ≤ 80Km | |
最大爬坡度 Maximum gradient | ≤20% Maximum gradability: ≤20% | |
充電輸入電壓 Charge input voltage | 220v Charging input voltage: 220V |
