型 號:SHT2412
電 機:安乃達400W高效節能電機
控制器:大六管無線控制器
電 池:48V20Ah,天能/超威品牌鉛酸電池
顏 色:客戶可定制
蘇華特 SHT2412 電動摩托車 技術參數(出口型)
Suhuate SHT2412 Electric Motorcycle - Technical Parameters (Export Version)
產 品 Product | 名稱 Name | 電動兩輪摩托車 Electric Two-wheeled Motorcycle |
品牌 Brand | 蘇華特 SUHUATE | |
型號 Type | SHT2412 | |
電 器 系 統 Electrical system
| 電控 Electric control | 大六管無線控制器Six - transistor Wireless Controller |
電池 Battery | 48V20Ah,天能/超威品牌鉛酸電池48V20Ah Tianneng/Chilwee Brand Lead - acid Battery | |
電機 Motor | 安乃達400W高效節能電機Ananda 400W High - efficiency and Energy - saving Motor | |
電路系統 Circuit system | 全車防水接插件,分體式電源Full-vehicle waterproof connectors, with split-type power supply. | |
充電器 Charger | 48V 充電平穩、耐高溫With 48V, the charging process is stable and it can withstand high temperatures. | |
充電時間 Charging time | 6-8 小時 6-8 hours | |
音響Audio system | 電喇叭Electric horn | |
車 身 配 置 Body matching
| 車體 Body | 鋼制車架+塑料外殼 Steel frame + plastic shell |
儀表臺 Dashboard | 多功能液晶數碼儀表盤 ,功能齊全Dashboard: Multi - function LCD digital instrument panel with complete functions. | |
車架 Frame | 微型車車架,高強度鋼結構件.The frame is of a micro-car type, made of high-strength steel structural parts. | |
燈光及信號 Lights and signals | LED大燈,前后帶轉向燈 LED headlight with front and rear turn signals | |
顏色 Color | 紅色標準色 ,客戶可定制Standard red color, customizable by customers. | |
座椅 Seat | 770mm整體式海綿外包皮革座椅 ,舒適耐用。Seat: 770mmIntegrated sponge seat covered with leather, which is comfortable and durable. | |
底 盤 Bottom plate | 動力傳動系統Power transmission system | 無級調速系統 Stepless speed control system |
驅動系統 Drive system | 后軸驅動 Rear axle drive | |
減震Shock absorption | 精品后減震 High - quality rear shock absorption | |
制動系統 Brake system | 前后110mm鼓剎 Front and rear 110mm drum brakes | |
外形尺寸 長*寬*高 Size Length * Width * Height (mm) | 1560×660×1070 mm | |
軸距 Wheelbase | 1460 mm | |
輪胎 Tyre | 14×2.5 真空輪胎,鐵輪 14×2.5 vacuum tire, iron wheel | |
整車裝備質量 Vehicle curb weight | 63kg | |
整車載荷 Vehicle load-carrying capacity | 100kg | |
制動距離 Braking distance | ≤6.5 m | |
座額定乘員Rated passenger capacity | 2 人(含駕駛員) 2 persons (including the driver). | |
初速 30km/h 制動距離 Braking distance at an initial speed of 30km/h | ≤6.5 m | |
最大行駛速度 Maximum travel speed | 三檔變速,最高時速43km/h Three - speed transmission, maximum speed 43 km/h | |
續駛里程 Range | ≤ 65 Km | |
最大爬坡度 Maximum gradient | ≤ 20% | |
充電輸入電壓 Charge input voltage | 220v |
