品牌 Brand

蘇華特  Suhuate

型號 Type

TDR756Z

電 器 系 統   Electrical system

電控  Electric control

48V 智能化控制系統；無級調速，制動斷電， 欠壓保護 ，過流保護等性能 ，穩定。48V 共享專用控制器、多重保護

48V intelligent control system; Stepless speed regulation, braking power off, undervoltage protection, overcurrent protection and other performance, stable. 48V shared dedicated controller, multiple protection

電池 Battery

48V 24Ah 天能 錳酸鋰電池、共享專用鋰電池。耐低溫

48V 24Ah Tianneng lithium manganate battery

Lithium battery specially for sharing. It is resistant to low temperature.

電機 Motor

安乃達 48V 350W   永磁直流無刷電機；高效電機，動力強勁，高效節能，續航里程長。

Aneda 48V 350W permanent magnet DC brushless motor; High efficiency motor, powerful power, high efficiency and energy saving, long driving range.

電路系統Circuit system

全車防水、阻燃插件，騎行更安全

Whole waterproof, flame retardant plug-in, more safe riding

車 身 配 置   Body matching

顏色colour

客戶可定制/青桔綠+灰  Customizable/Green orange + grey

車體Body

鋼制車架+塑料外殼   Steel frame + plastic shell

儀表 Instrument panel

多功能黑莓全面屏數碼儀表盤，功能齊全

Multifunctional blackberry Full screen digital dashboard, full of features

車架 Frame

新國標鋰電車車架，高強度鋼結構件；整車 采用大踏板 ，前后避震 ，結構硬朗、扎實、 穩定。New national standard lithium tram frame, high-strength steel structure; The whole vehicle adopts large pedal, front and rear shock absorber, the structure is strong, solid and stable

前叉 Front fork

Q195 無縫鋼管材質 ，外加塑料防護套

Q195 Seamless steel tube material with plastic protective sheath

燈光及信號 Lights and signals

透鏡 LED 大燈 ，前照燈 ，后尾燈帶剎車燈

Lens LED headlights, headlights, rear taillights with brake lights

前減震 Front shock absorber

液壓前減   Hydraulic forward reduction

后減震 Rear shock absorber

帶阻尼后減震   Rear shock absorption with damping

定制貼字Custom labeling

可根據使用單位要求定制貼字It can be customized according to the requirements of the user

底 盤   Bottom plate

動力傳動系統 Power transmission system

無級調速系統   Stepless speed control system

驅動系統  Drive system

后軸驅動   Rear axle drive

制動系統  Brake system

前鼓剎,后鼓剎 ，性能優越   Front and rear drum brake, superior performance

外形尺寸 長*寬*高(mm)

Size Length * Width * Height (mm)

1600mm×640mm×1050mm

整車質量Vehicle mass

55kg

整車荷Vehicle load

75kg

軸距 Wheelbase

1200mm

輪胎  Tyre

16 ×2.5-412 耐磨輪胎

額定乘員Rated occupant

1人

制動距離 Braking distance

≤6.6 m

最大行駛速度  Maximum travel speed

≤25km/h

續駛里程  Range

≤70km

最大爬坡度 Maximum gradient

≤15%

充電輸入電壓  Charge input voltage

220v

備注Note

車輛配置貨架、鐵欄筐（定制）

The vehicle is equipped with a shelf and a customized iron railing basket.
