品牌

Brand

蘇華特

SUHUATE

型號

Type

SHT2561

外形尺寸 長*寬*高

Size Length * Width * Height (mm)

1980mmX730mmX1150mm

電 器 系 統   Electrical system

控制器規格

Controller specification

72V4000W專用智能化控制器；無級調速，制動斷電，欠壓保護，過流保護等性能，穩定。72V 控制器，強勁快速，自動修復。

72V4000W  intelligent control system; Stepless speed regulation, braking power off, undervoltage protection, overcurrent protection and other performance, stable. 72V controller, powerful, fast, automatic repair.

電池

Battery

72V 30Ah 大容量磷酸鐵鋰電池，國內一線品牌鋰電池，BMS參數根據4000W電機和4000W控制器匹配的參數進行設定

72V 30Ah large capacity lithium iron phosphate battery, domestic first-line brand lithium battery, BMS parameters are set according to 4000W motor and 4000W controller matching parameters

可同時安裝兩組72V30Ah磷酸鐵鋰電池

Two 72V30Ah lithium iron phosphate batteries can be installed at the same time

電機規格

Rating of machine

14寸，4000W直流永磁

14 inch, 4000W DC permanent magnet

電機額定輸出功率

Rated output power of motor

4000W

電路系統

Circuit system

全車防水、阻燃插件，騎行更安全

Whole waterproof, flame retardant plug-in, more safe riding

充電器

Charger

72V 鋰電充電器，耐用、安全、充電平穩、耐高溫

72V lithium charger, durable, safe, stable charging, high temperature resistance

充電時間

Charging time

2-4小時

2-4 hours

充電使用電源

Power supply for charging

220V-50HZ

車 身 配 置   Body matching

車體

Body

鋼制車架+塑料外殼

Steel frame + plastic shell

儀表

Instrument panel

LED

燈具

Luminaire

LED

轉向燈

Turn signal

LED

車架

Frame

鋰電專用車架，高強度鋼結構件；整車采用大踏板，前后避震，結構硬朗、扎實、穩定。

Lithium battery special frame; The whole vehicle adopts large pedal, front and rear shock absorber, the structure is strong, solid and stable.

前叉

Front fork

液壓帶阻尼無縫管材質，外加塑料防護套

Hydraulic belt damped seamless tube material, plus plastic protective jacket

燈光及信號

Lights and signals

透鏡LED大燈，前照燈，前左、右轉向燈：組合后尾燈，配置左、右轉向燈。電喇叭；凌厲霸氣的水晶的前大燈，按照仿生學原理設計，外形更美觀，照明更安全

Lens LED headlights, headlights, front left and right turn signals: combined rear taillights, equipped with left and right turn signals. Electric horn; The crystal headlights are designed according to the principle of bionics, which makes the appearance more beautiful and the lighting more safe

遙控器及防盜器

Remote control unit and burglar alarm

配置智能化遙控器，智能化防盜器

Intelligent remote control, intelligent anti-theft device

減震器規格（前/后）

Shock absorber Specifications (front/rear)

前、后液壓減震；前后全液壓，后雙減震

Front and rear hydraulic shock absorption; Full hydraulic front and rear, dual shock absorption rear

底 盤   Bottom plate

動力傳動系統

Power transmission system

無級調速系統

Stepless speed control system

驅動系統

Drive system

后軸驅動

Rear axle drive

制動型式（前/后）

Brake type (front/rear)

碟剎，220mm剎盤

Disc brake, 220mm brake disc

制動方式（前/后）

Braking mode (front/rear)

碟剎/碟剎

Disc brake/Disc brake

前后輪軸距

Front and rear wheelbases

1440mm

輪胎規格（前/后）

Tire Specifications (front/rear)

前16寸后14寸

16 inches front, 14 inches back

前100/80/16   后：110/80/14

First 100/80/16 Post: 110/80/14

制動距離

Braking distance

≤6.5 m

最大行駛速度

Maximum travel speed

≥100km/h

續駛里程

Range

≥150km

最大爬坡度

Maximum gradient

≥12°

充電輸入電壓

Charge input voltage

220v

欠壓保護值

Undervoltage protection value

51.5±0.5V

定制線路，快遞專用

Customized lines, express only

可帶IOT手機遠程操控

Remote control with IOT mobile phone

加強型底座，載貨專用

Reinforced base, special for cargo
